螺杆空压机
服务咨询热线:
13122909250GM-20A PM 永磁变频空压机
型号 | 功率(kw) | 排气压力(Mpa) | 排气量(m³/min) | 出口尺寸 | 机组重量(kg) | 外形尺寸 |
GM-10A PM | 7.5 |
0.8 1.0 1.3 |
1.1 0.9 0.7 |
G1/2 | 180 | 900*650*850 |
GM-15A PM | 11 |
0.8 1.0 1.3 |
1.7 1.6 1.0 |
G3/4 | 300 | 1000*740*1100 |
GM-20A PM | 15 |
0.8 1.0 1.3 |
2.3 2.0 1.6 |
G3/4 | 320 | 1000*740*1100 |
GM-30A PM | 22 |
0.8 1.0 1.3 |
3.4 3.2 2.7 |
G1 | 420 | 1070*840*1260 |
GM-40A PM | 30 |
0.8 1.0 1.3 |
5.0 4.0 3.1 |
G1 | 450 | 1070*840*1260 |
GM-50A PM | 37 |
0.8 1.0 1.3 |
6.1 5.4 4.7 |
G1 1/2 | 600 | 1200*1000-1390 |
GM-60A PM | 45 |
0.8 1.0 1.3 |
7.2 6.6 5.7 |
G1 1/2 | 700 | 1200*1000-1390 |
GM-75A PM | 55 |
0.8 1.0 1.3 |
9.8 8.2 6.7 |
G2 | 920 | 1700*1200*1500 |
GM-100A PM | 75 |
0.8 1.0 1.3 |
9.1 11.8 13.0 |
G2 | 950 | 1700*1200*1500 |
GM-125A PM | 90 |
0.8 1.0 1.3 |
15.2 13.3 11.4 |
G2 | 1350 | 2100*1650*1900 |
GM-150A PM | 110 |
0.8 1.0 1.3 |
19.9 16.3 14.5 |
DN80 | 2650 | 2500*1650*1900 |
GM-180A PM | 132 |
0.8 1.0 1.3 |
23.0 19.7 16.0 |
DN80 | 2850 | 2500*1650*1900 |
GM-220A PM | 160 |
0.8 1.0 1.3 |
27.0 22.5 21.0 |
DN80 | 4100 | 3000*1900*1950 |
GM-250A PM | 185 |
0.8 1.0 1.3 |
30.0 27.0 23.0 |
DN80 | 4300 | 3000*1900*1950 |
GM-270A PM(风冷) | 200 |
0.8 1.0 1.3 |
32.5 29.2 25.5 |
DN100 | 5300 |
3600*2200*2200 3250*1950*1850 |
GM-300A PM(风冷) | 220 |
0.8 1.0 1.3 |
38.0 32.0 28.8 |
DN100 | 5500 |
3600*2200*2200 3250*1950*1850 |
GM-340A PM(风冷) | 250 |
0.8 1.0 1.3 |
43.0 37.5 31.5 |
DN100 | 5800 |
3600*2200*2200 3250*1950*1850 |
